The ATV that just loves to get stuck in. The Foreman is a heavy-hitting ATV built for hard work and hauling big loads – day in, day out. 2,809km. All used ATVs come fully serviced and with a three-month warranty.
£9,360.00 INC VAT
We offer a click and collect service, simply add the item to your basket and then choose your collection date at the checkout.
The ATV that just loves to get stuck in. The Foreman is a heavy-hitting ATV built for hard work and hauling big loads – day in, day out. 2,809km. All used ATVs come fully serviced and with a three-month warranty.
Classification: Heavy duty ATV
Engine: 518cc liquid cooled, longitudinally mounted single-cylinder four-stroke
Carburation: PGM-FI 36mm
Ignition Full-transistorized with electronic advance
Starter Electric
Transmission: Manual 5 speed + reverse
Drive Direct front and rear driveshafts with TraxLok™ and locking front differential.
Front Suspension: Double wishbone; 185mm travel
Rear Suspension: Independent dual-arm; 215mm travel
Power Steering: Yes
Front Brakes: 190mm dual hydraulic discs
Rear Brakes: 170mm single hydraulic disc
Front tyres: 25 x 8-12
Rear tyres: 25 x 10-12
Fuel Capacity (l): 14.7L, incl. 4.9L res.
Bore x Stroke (mm): 96.0 x 71.5
Dimensions – Length (mm): 2140
Dimensions – Width (mm): 1200
Dimensions – Height (mm): 1230
Wheelbase (mm): 1290
Seat Height (mm): 910
Ground Clearance (mm): 240
Towing Capacity (kg): 599
Front Rack Capacity (kg): 99 pounds
Rear Rack Capacity (kg): 87 pounds
Three-month warranty
2025 Honda Foreman 520 TRX520FM6 (AMU1478)
The ATV that just loves to get stuck in. The Foreman is a heavy-hitting ATV built for hard work and hauling big loads – day in, day out. 2,809km. All used ATVs come fully serviced and with a three-month warranty.
Big loads, long days – no problem. The Honda Foreman is built to deliver solid handling and powerful performance with renowned durability, whatever the conditions.
With huge low down torque delivered by a new, larger fuel efficient liquid cooled 518cc engine, and its computer-engineered chassis providing smooth, sure footed handling, the Foreman truly is a joy to ride.
Here at Agrimark we credit ourselves on having Honda Specialist trained Technicians and purpose-built workshop with full access to Honda Genuine parts. We have combined experience of over 70+ years mechanical knowledge and 40+ years Honda specialist training.
